PFA Wire

1.PFA wire is silver plated copper wire conductor PFA insulated teflon wire.
2.PFA wire belong to excellent high temperature wire with 250℃.The cost is lower than PTFE wire.
3.Advantage of PFA wire: water and oil resistant,corrosion resistant, it is very strong with high tensile strength.

Send Inquiry

Description

High temperature Resistant PFA Teflon Wire

High temperature Teflon Wire with PFA insulation named for PFA Wire,type is AF250. PFA wire not only resist high temperature +260℃,it can also resist low temperature till -200℃.

Main technical parameters for PFA Wire:

Rated voltage：600V and below
Test of power-frequency withstand voltage： 3000V
Temperature range：-80～+260℃
Conductor: silver plated copper, or tinned copper
Insulation: teflon PFA
Color：red black yellow blue green white orange purple brown, other more colors can be customized.

Hot sale size of teflon PFA Wire: 0.35mm, 0.5mm,0.75mm, 1.0mm, 1.5mm

Hot sale UL gauge: 22 awg, AWG20, 18 gauge, 16 guage, awg14,awg12 , awg10 ,awg8

Application:

Teflon PFA wire is widely used for electronic instrument equipment, aerospace field, medical and chemical industry, various electronics and electrical appliances,lighting equipment,small electric motor, electromagnetic coils, automotive temperature sensor connection to lead,automotive internal connection line ,and other. PFA wire can be used in air-conditioning equipment， micro-wave oven， electric disinfectant cupboard， electric cooker， electric thermos， electric heater， electric oven， lamps and lanterns in their inner wire and so on.

PFA Wire Advantage and product features：

PFA teflon wire has the excellent chemical and mechanical property.Teflon PFA wire is corrosion-resistance，Oil resistant，strong acid-resistance， strong alkali-resistance，oxidant-resistant.It can bear the good electric insulated capability，moisture-resistance, flame-retardant， Anti-ageing,PFA wire has long age of usage.

Conductor			Insulation		Electrical Properties	Packing
Sectional Area mm²	Conductor Construction NO.×φmm	Diameter mm	Insulation Thickness mm	Outer Diameter mm	Max.Conductor Resistance DC 20℃ Ω/m	M/coil
0.05	7×0.1	0.3	0.2	0.7	376.2	500
0.2	7×0.2	0.6	0.3	1.2	83.5	500
0.35	19×0.16	0.8	0.3	1.4	49.5	200
0.5	19×0.18	0.9	0.35	1.6	36	200
0.75	19×0.23	1.15	0.35	1.85	22.7	200
1	19×0.26	1.3	0.35	2	19	200
1.2	19×0.28	1.4	0.35	2.1	15.3	200
1.5	19×0.32	1.6	0.4	2.4	11.7	200
2	19×0.37	1.85	0.4	2.65	9.45	100
2.5	19×0.41	2.05	0.5	3.05	6.86	100
4	37×0.37	2.6	0.5	3.6	4.51	100
6	37×0.45	3.15	0.5	4.15	3.05	100
10	133×0.32	4.8	0.5	5.8	1.68	100
16	133×0.39	5.8	0.6	7	1.13	100
20	133/0.45	6.8	0.6	8	0.886	100
25	199/0.4	7.6	0.6	8.8	0.734	100
35	494/0.3	9	0.7	10.4	0.511	100
50	551/0.4	10.6	0.8	12.2	0.358	100
70	551/0.4	12.6	1	14.6	0.27	100
95	760/0.4	14.8	1.2	17.2	0.21	100

Remarks:

Here just list one part of our teflon PFA wire. We can produce more and different specifications according to customer’s special requirements,UL type and specification can be done, pls contact us and we will send you more specifications if you need other standard teflon wire.
