Description of silicone wire:
500V 1000V Flexible Tinned copper conductor silicone rubber insulated Silicone wire
Type name: JG flexible silicone wire
Rated Voltage: 500V, 1000V
Temperature Ratings: -60ºC~+180ºC
Application:.
Silicone wire is widely used for various electric machines，motor,household appliances, electric ceramics ,heating elements parts, electric inspection equipment, car lights,Auto lamps,lighting lamp, barretter etc,for High temperature resistant wire cable environment.
Cable Structure for Flexible Silicone Wire:
Conductor: bare copper or Tinned copper stranded wire
Insulation: Silicone Rubber
Allowed OD tolerance for silicone wire: ±0.1mm
Color: Black,Brown ,Red, Green,purple, White, Gray, Transparent,other more colors can be customized by the customer’s requirements.
Specification for 500V 1000V flexible silicone wire
Usual size: from 0.5mm,0.75mm,1.0mm,1.5mm.........up to 240mm
Hot sale specification: 0.75mm,1.0mm,1.5mm, 2.0mm, 2.5mm , 4.0mm
UL specification for low voltage Flexible Silicone wire:
Rated voltage: 300V 600V
Temperature Ratings: -60ºC~+200ºC
Hot sale UL silicone wire: UL3135,UL3142, UL3529,UL 3530
Hot sale UL specification: 10awg,12gauge,14 awg, 14 gauge, 16 gauge, 18 gauge 20awg
Technical Data List for low voltage Flexible silicone wire
|
| Outer Diameter |
| ||||
|
| Diameter | 500V | 1000V | 500V | 1000V | Max.Conductor |
0.5 | 28/0.15 | 0.9 | 1 | 1.2 | 2.9 | 3.3 | 40.1 |
0.75 | 24/0.2 | 1.15 | 1 | 1.2 | 3.2 | 3.6 | 26.7 |
1 | 32/0.2 | 1.3 | 1 | 1.2 | 3.3 | 3.7 | 20 |
1.5 | 48/0.2 | 1.6 | 1 | 1.2 | 3.6 | 4 | 13.7 |
2 | 40/0.25 | 1.85 | 1 | 1.2 | 3.9 | 4.3 | 9.9 |
2.5 | 49/0.25 | 2 | 1 | 1.2 | 4 | 4.4 | 8.21 |
4 | 56/0.3 | 2.8 | 1.2 | 1.4 | 5.2 | 5.6 | 5.09 |
6 | 84/0.3 | 3.6 | 1.2 | 1.5 | 6 | 6.6 | 3.39 |
10 | 84/0.4 | 4.6 | 1.4 | 1.6 | 7.4 | 7.8 | 1.95 |
16 | 126/0.4 | 5.8 | 1.4 | 1.6 | 8.6 | 9 | 1.24 |
25 | 196/0.4 | 7.6 | 1.6 | 1.8 | 10.8 | 11.2 | 0.795 |
35 | 494/0.3 | 8.8 | 1.8 | 2 | 12.4 | 12.8 | 0.565 |
50 | 396/0.4 | 10.6 | 2 | 2.2 | 14.6 | 15 | 0.393 |
70 | 551/0.4 | 12.8 | 2 | 2.2 | 16.8 | 17.2 | 0.277 |
95 | 760/0.4 | 14.8 | 2.2 | 2.5 | 19.2 | 19.8 | 0.21 |
120 | 608/0.5 | 16.5 | 2.2 | 2.5 | 21 | 21.5 | 0.164 |
150 | 760/0.5 | 18.2 | 2.4 | 2.6 | 23 | 23.4 | 0.132 |
185 | 925/0.5 | 20 | 2.4 | 2.6 | 24.8 | 25.2 | 0.108 |
240 | 1221/0.5 | 23 | 2.6 | 2.8 | 28.2 | 28.6 | 0.0817 |
