Henan Verde Cable Co., Ltd. is one of the leading manufacturers and suppliers of ptfe insulated tin plated copper braided shielded high-temperature wire in China, featured by quality products and good price. If you're going to wholesale durable ptfe insulated tin plated copper braided shielded high-temperature wire made in China, welcome to get price list from our factory.
Product Information Sheet of Wellde® High Temperature Wire
| Item | Parameter Details |
|---|---|
| Conductor | Stranded Bare Copper Conductor |
| Inner Insulation | PTFE Tape Wrapped Insulation |
| Shielding Layer | Tinned Copper Braid Shield |
| Rated Voltage | 600V |
| Continuous Operating Temperature | -200℃ ~ +260℃ |
| Shielding Performance | 100% Coverage, Blocks EMI/RFI Electromagnetic Interference |
| Certificates | RoHS, SGS Material Report, Factory Test Report |
Advantages of Wellde® high-temperature wire products
1. PTFE film wrapped insulation, continuous high temperature of 260 ℃ will not soften or deform
2. Tin plated copper braided full coverage shielding can effectively isolate electromagnetic interference caused by motors and frequency converters
3. Low dielectric loss, stable signal transmission
4. The wire is soft and easy to bend, making wiring assembly easier.
Technical Reference Table
The above data is for reference only. The product specifications are subject to mutual confirmation by both parties
|
Conductor |
Insulation |
Electrical Characteristic |
||||||
|
AWG |
No.xΦmm |
Stranded OD |
Insulation Thickness |
OD |
Conductor Resistance |
Dielectric Strength AC |
||
|
1 |
836 |
× |
0.254 |
9.00 |
1.14 |
11.30 |
0.45 |
2500V |
|
2 |
684 |
× |
0.254 |
8.04 |
0.76 |
9.56 |
0.55 |
|
|
4 |
133 |
× |
0.45 |
6.20 |
0.76 |
7.70 |
0.9 |
|
|
6 |
133 |
× |
0.36 |
4.90 |
0.76 |
6.40 |
1.4 |
|
|
8 |
133 |
× |
0.284 |
3.90 |
0.76 |
5.40 |
2.3 |
|
|
10 |
37 |
× |
0.43 |
3.06 |
0.51 |
4.08 |
3.5 |
|
|
12 |
19 |
× |
0.47 |
2.35 |
0.51 |
3.37 |
5.8 |
|
|
14 |
19 |
× |
0.37 |
1.85 |
0.51 |
2.87 |
9.3 |
|
|
16 |
19 |
× |
0.30 |
1.50 |
0.51 |
2.50 |
14 |
|
|
18 |
1 |
× |
1.02 |
1.02 |
0.51 |
2.04 |
24 |
|
|
7 |
× |
0.40 |
1.20 |
0.51 |
2.20 |
23 |
||
|
19 |
× |
0.235 |
1.18 |
0.51 |
2.20 |
23 |
||
|
20 |
1 |
× |
0.80 |
0.80 |
0.51 |
1.80 |
38 |
|
|
7 |
× |
0.32 |
0.96 |
0.51 |
1.98 |
35 |
||
|
19 |
× |
0.185 |
0.93 |
0.51 |
1.98 |
35 |
||
|
22 |
1 |
× |
0.65 |
0.65 |
0.51 |
1.67 |
57 |
|
|
7 |
× |
0.25 |
0.75 |
0.51 |
1.80 |
55 |
||
|
19 |
× |
0.15 |
0.75 |
0.51 |
1.80 |
50 |
||
|
24 |
1 |
× |
0.50 |
0.50 |
0.51 |
1.50 |
97 |
|
|
7 |
× |
0.20 |
0.60 |
0.51 |
1.60 |
86 |
||
|
19 |
× |
0.12 |
0.60 |
0.51 |
1.60 |
88 |
||
|
26 |
7 |
× |
0.16 |
0.48 |
0.51 |
1.50 |
135 |
|
|
28 |
7 |
× |
0.12 |
0.36 |
0.51 |
1.38 |
240 |
|
|
30 |
7 |
× |
0.10 |
0.30 |
0.51 |
1.32 |
346 |
|
Packaging&Delivery
Packaging: Large quantities of goods use plastic wire spools wrapped with waterproof film on the outer layer; Use a hard cardboard box for the sample to prevent scratching of the weaving layer and damage to the PTFE insulation.
Delivery time: 7-10 days for regular specifications in stock; Customized specification orders take 15-25 days.
Trade terms: EXW/FOB/CIF are acceptable, and sea or air freight can be arranged.
FAQ
Q1: What are the benefits of tin plated copper braided shielding layer?
A1: Full coverage weaving has almost no signal leakage, and tin plating treatment can prevent copper wire from oxidizing and rusting in high temperature environments, extending the service life of the wire.
Q2: Can this shielded high-temperature wire directly come into contact with hot oil?
A2: PTFE insulation is resistant to most oils and can withstand short-term contact with hot oil without any problems; For long-term immersion conditions, please inform us in advance of the medium temperature so that we can evaluate the plan.
Q3: Can I make a multi-core version of PTFE tin plated copper shielded high-temperature wire?
A3: Yes, 2-core, 3-core, and multi-core structures can be customized.
Q4: Can we send samples for high temperature+shielding testing?
A4: Sample segments can be taken for customers to conduct performance testing, and the sample shipping cost can be negotiated between both parties.
