Product technical specification definition
1. Basic wire type: UL2651 gray flat ribbon cable
2. Standard center spacing: 1.27mm
3. Optional pin position specification: 4P to 64P full pin count customization
4. Connection method: IDC piercing type compression connection, solderless structure
5. Protective structure: Segmented black heat shrink insulation sheath at the outlet position
Electrical and physical performance parameters of flat ribbon cable
1. Electrical performance: Rated voltage 300V, rated current for single core 3A, insulation resistance ≥ 100MΩ, withstand breakdown voltage meets the standard for conventional low-voltage control circuits
2. Bend life: The reinforced position of the sheath can be repeatedly bent for ≥ 5000 times without cracking or core breakage, meeting the long-term vibration conditions for equipment use
3. Contact reliability: After IDC piercing terminal is pressed, the pulling force meets the standard, the pulling force does not cause the wire to come loose, and the contact resistance fluctuates extremely little in both low and normal temperatures
4. Operating temperature range: Conventional -20℃ to +80℃, custom-made with modified high-temperature materials to adapt to the internal environment of high-temperature equipment
Compared with ordinary bare cable lines, the unique advantages of this product
1. Ordinary bare cable line: Only the two ends are crimped with terminals, and it cannot branch in the middle. It is prone to cracking and breaking the insulation when bent, and the protection is weak.
2. This model of insulated segmented IDC cable line: Supports multiple nodes for outgoing lines at the middle part, provides local enhanced protection, offers a more flexible wiring scheme, has a longer service life, and results in a lower overall long-term usage cost.
Application selection direction
Internal wiring of industrial control motherboards, internal signal acquisition lines of instruments and meters, wiring harnesses for automation sensors, internal wiring of intelligent equipment control panels, and internal jumper assemblies of low-voltage electrical cabinets.
Packaging
Rolling, boxing, foam, etc. All these measures protect the outer sheath, core wire and shielding structure of the cable, making it less prone to damage during sea and land transportation.
