Advantage and Application for 3 Core XLPE Cable:
In comparison with PVC insulation cable, it boasts not only excellent electric character, mechanical character, heat and aging-resistant character, environmental stress-resistant character and chemical corrosion- resistant character, but simple structure, light weight, no restriction by laying drop, and high temperature allowance for long-term working as well. So also used for industrial field, agricultural field, chemical factory, and hospital.
Rated Voltage of 3 Core XLPE Cable:
600/1000V according to GB/T12706, IEC60502,
AC voltage test of cable:
Test voltage 3.5kV
Test time: 5min
Size and Specifications for 3 Core XLPE Cable:
3x10mm, 3x16mm..3x.35mm.3x50mm.3x95mm2..3x185mm2...300mm2
AWG size: AWG3, AWG2,AWG1...AWG1/0 AWG 2/0 , AWG 4/0 .......more AWG sizes cables can be customized.
Type Description & Application Occasion of cable
Type name | Description | Application | |
Cu conductor | Al conductor | ||
YJV | YJLV | XLPE insulation PVC sheath power cable | To be laid indoors, in tunnel, cable furrow or pipe, the cable couldn't bear mechanical force outside |
YJY | YJLY | XLPE insulation PE sheath power cable | |
YJV22 | YJLV22 | XLPE insulation, steel tape armor, PVC sheath power cable | To be laid underground, the cable could bear certain mechanical force, but it couldn't bear great pulling force. |
YJV32 | YJLV32 | XLPE insulation, thin steel-wire armor, PVC sheath power cable | Be applicable to the well, water inside and fall in the bad soil, the cable cans bear the equal dint outside the machine with pull the dint |
0.6/1kV 3-core XLPE insulation PVC sheath power cable
Nominal Area mm2 | Non armored | Steel Tape-armored | Steel Wire-armored | |||||||
Reference diameter mm | Approximate weight kg/km | Reference diameter mm | Approximate weight kg/km | Ref. OD of the cable mm | Approximate weight kg/km | |||||
YJV | YJLV | YJV22 | YJLV22 | YJV32 | YJLV32 | |||||
3*6 | 15.5 | 376 | 264 | 17.9 | 526 | 414 | / | / | / | |
3*10 | 18.3 | 545 | 359 | 20.7 | 722 | 536 | / | / | / | |
3*16 | 20.6 | 757 | 460 | 23.0 | 956 | 658 | / | / | / | |
3*25 | 20.2 | 857 | 485 | 22.6 | 1052 | 680 | 28.0 | 1955 | 1487 | |
3*35 | 22.0 | 1298 | 647 | 24.4 | 1510 | 859 | 27.3 | 2171 | 1516 | |
3*50 | 25.3 | 1794 | 865 | 27.9 | 2050 | 1121 | 30.6 | 2761 | 1825 | |
3*70 | 28.5 | 2426 | 1125 | 30.9 | 2697 | 1397 | 34.8 | 3811 | 2500 | |
3*95 | 32.3 | 3233 | 1468 | 36.1 | 3897 | 2132 | 38.3 | 4734 | 2956 | |
3*120 | 35.1 | 3990 | 1760 | 38.9 | 4710 | 2479 | 43.4 | 6178 | 3931 | |
3*150 | 38.8 | 4949 | 2161 | 42.8 | 5761 | 2973 | 47.6 | 7403 | 4596 | |
3*185 | 42.9 | 6078 | 2640 | 47.1 | 6985 | 3547 | 52.1 | 8804 | 5341 | |
3*240 | 48.1 | 7807 | 3347 | 52.3 | 8821 | 4361 | 57.3 | 10747 | 6255 | |
3*300 | 53.0 | 9676 | 4100 | 57.2 | 10788 | 5213 | 61.9 | 12822 | 7206 | |
Our Medium Voltage 3 Core Wire 11kv 15kv 33kv Underground Copper Electric XLPE Mv Power Cable has a wide range, complete sizes and conform to international and domestic standards. We hope that the company will strive to maintain sustained profit growth and capacity enhancement to ensure the long-term prosperity of the company. We insist on following the trend, doing our best to promote the company to achieve new development, to a new height and to create a new situation!
