450/750V Copper Core, Copper Wire Braided Shielded Control Cable

The company's products are rich in variety, especially 2 Core Flexible Cord, White Spiral Cable, Spiral Cable For Truck, which sells well in domestic and foreign markets due to its high quality. We recognize that in order to ensure proper business operations and to continuously enhance corporate value, it is critical to implement and maintain a risk management system to address the serious risks that may be faced in business operations. We believe that honesty is the basis of employee's foundation, employees should be honest with the enterprise, and employees should also be honest with each other. If you are interested in our company's products, look forward to your inquiries, we are willing to work together with you to create a brillant future!

Structure of Copper Wire Braided Shielded Control Cable ：

• Conductor：Oxygen free Copper stranded wires

• Insulation：PVC / ROHS PVC

• Screen / Shielded: Copper wire braid and Aluminum foil screen

• Sheath：Polyvinyl chloride PVC flame retardant

• Reference Standard: 60227 IEC 74

• Type: copper control cable KVVP

Specification for Copper Wire Braided Shielded Control Cable:

Technical Data for braided screen control cable :

Rated Voltage: U0/U = 300/500V, 450/750V, 600/1000V

Test Voltage: 2000V, 2500V, 3500V

Range of Temperature: -40℃~+70℃(fixed), -50℃~+70℃(flexing)

Min Bending Radius: 6×0(fixed), 20×0 (flexing)

Core Identification: Color Coded, Number coded

Conductor Stranding: IEC 60228 C1.5

Application of Copper Wire Braided Shielded Control Cable:

The shielded / screen control cable is suitable for communicating with the AC rated current 450/750V and the electrode connecting wires of the instrument panels of the following household appliances and the coaxial cables of the automatic control system. Screened cables provide interference-free data and signal transmissions and greater electromagnetic protection from electrical drives and frequency converters.

Feature of copper wire braided shielded control cable:

● Flame-retardant,

● Oil-resistant,

● Torsion resistant,

● Resistant to chemical corrosion.

● Copper wire braided shielding can well shield the interference of interfering signals. If XLPE insulation is required, it is also feasible.

Technical and management innovation is our relentless pursuit, and we will do our utmost to promote our 450/750V Copper Core, Copper Wire Braided Shielded Control Cable upgrades and industry development. Our company always insists on the business philosophy of "taking customers' interests as the core, and developing and producing cost-effective products as the fundamental". We believe that with rich professional service experience and excellent product performance, we will be able to meet your needs best.
